Paper Prototyping Supplies List

Here are links to various paper prototyping supplies on Staples.com and OfficeDepot.com. I am providing these links as a convenience - I make no guarantees about these items. Some items may not be available for shipping to your location. I have no financial interest in these companies.

Item

Amount needed

Links to Staples.com, OfficeDepot.com

Usage/Notes

Lightweight posterboard or heavy paper, 11x14 or larger

2-3 pieces

Staples 11x14

Office Depot 22x28 (cut it in half)

Fixed background upon which the paper prototype elements are placed. Use a size that's larger than 8.5x11 paper - prototypes are usually somewhat larger than life size.

Blank write-on transparencies

3 pieces

Staples

OfficeDepot

Placed over the prototype, it allows the user to "type" (handwrite) data without altering the prototype. I use transparency when there are more than a half dozen fields to complete, otherwise I use removable tape.

Wet-erase transparency pen

1 or 2

Staples OfficeDepot

For writing "typed" input on a piece of transparency laid on top of the prototype. (Permanent pens work too, but you'll use more sheets of transparency.)

Unlined index cards (5x8 and 4x6)

Pack of 100

Staples: 5x8, 4x6

OfficeDepot: 5x8, 4x6

Prototype pieces: dialog boxes, pop-up messages, drop-down menus, etc. Regular paper is OK, but card stock is sturdier and holds up better under repeated use.

Removable tape (Post-It brand), varying widths

1 roll each size

Staples: 2-line, 6-line

OfficeDepot: 2-line, 6-line

Use the 2-line width for edit fields (especially if the data appears elsewhere in the interface), small amounts of text that change, status line messages, and list elements. The larger size is good for grayed buttons and quick fixes to the prototype.

Fine-point markers

1 set

Staples

OfficeDepot

Used for hand-drawing the prototype. You want something with a thick enough line so you draw a bit larger than life size - this helps observers to see. I use sets of inexpensive colored art markers because I think they encourage creativity, but color usually isn't necessary.

Correction fluid (e.g., White-out)

1 bottle

Staples

Office Depot

For small changes to the prototype, such as wording. You have to let correction fluid dry before you can write on it. In a usability test, I prefer to use removable tape to make quick fixes.

Scissors

1 pair

Staples

Office Depot

Sometimes it's helpful to cut screen shots into pieces, if only part of the interface changes at a time.

Highlighter

1 or 2

Staples

Office Depot

Used with transparency for making a highlight of the currently selected item. Light colored translucent plastic of some kind would be even better.

Transparent tape 1 roll

Staples

Office Depot

For attaching prototype pieces permanently, such as creating a dialog box out of two index cards. For less permanent attachment, use removable glue.
Restickable glue 1 stick

Staples

Office Depot

Like the glue on sticky notes, it keeps elements of the prototype in place until you're ready to move them. Useful if you have a prototype with many separate elements that change individually, such as a web site that uses frames.
